Features
For UFS only
- Support UFS 2.0, UFS 2.1, UFS 3.0及UFS 3.1
- Support MIPI M-PHY V3.0
- UniPro Specification V1.6
- UFS Card Extension V1.0
- Support up to 2 Lane Gear 3 (Rate A/ Rate B)
- Support 19.2MHz / 26MHz RCLK frequency
- Support UFS LUN read/write
- Support all settings such as Descriptor and Attributes
- 64G internal memory (expandable)
- Support USB 3.1 Gen1 (USB3.0) with download speed up to 280 MB/s
Ultra high UFS programming speed
- Program speed up to 230 MB/s
- Verify speed up to 880 MB/s
Excellent programming performance
- Cutting-edge programming core delivers the fastest and most stable programming performance on high-density NAND Flash and eMMC
- Full IC pin contact check prevents bad contact in socket or IC damage from reversed placement
Support IC types & packages
-
Exclusive programming core for UFS IC
-
Support SOP, TSOP, QFP, BGA, QFN, SON, WLCSP, etc.
High data transfer speed
-
USB3.1 Gen 1 (USB3.0) transferring interface significantly increase the programming speed
User-friendly software interface
-
Intuitive graphical user interface
-
Clear display of each function in the entire programming procedure
-
Display details and status of each device during programming
Timely software support
-
Fast software support by customer’s request
-
The supporting software is updated weekly on HI-LO website for checking or retrieving
-
All programming problems will be followed and handled immediately
ALL-300Ufs Core
ALL-300Ufs Core
New generation high-performance core：
New design of high-performance hardware, provides high speed and quality exclusively for UFS programming
- Support UFS IC only
- Full IC pin contact check prevents bad contact in socket or IC damage from reversed placement
- Outstanding speed: Program function delivers 230MB/s and Verify function delivers 880MB/s
Industries
This product is used in mobile, automotive, and consumer electronics
industries.
